Hot sale 1KW 2KW 3KW 4KW 5KW Off Grid Wind Turbine Generator
Regular price
$8,575.60
Professional 5kw wind turbine price vertical wind turbine
Product Description
Features:
1. Designed to be portable, light in weight, simple in structure and reliable in operation 2. The fan blades are made of
high-strength composite materials, with high strength, good toughness, anti-ultraviolet, anti-corrosion, high wind resistance,
good aerodynamic performance and unique strong wind stall protection characteristics. The mold is formed by one-time die-casting,
with small weight error and high production efficiency. 3. The bearing has high working efficiency, wear resistance and durability
for up to 15 years. 4. Adopt H-grade high temperature resistant enameled wire, which can withstand temperature up to 180℃. 5. The
magnets use NdFeB magnets, which have high efficiency, light weight, low energy consumption and high output power.
high-strength composite materials, with high strength, good toughness, anti-ultraviolet, anti-corrosion, high wind resistance,
good aerodynamic performance and unique strong wind stall protection characteristics. The mold is formed by one-time die-casting,
with small weight error and high production efficiency. 3. The bearing has high working efficiency, wear resistance and durability
for up to 15 years. 4. Adopt H-grade high temperature resistant enameled wire, which can withstand temperature up to 180℃. 5. The
magnets use NdFeB magnets, which have high efficiency, light weight, low energy consumption and high output power.
![](https://sc01.alicdn.com/kf/H93c63011de2a456e8a9b46cd98c44ee0k.jpg)
![](https://sc01.alicdn.com/kf/Ha1b71a59512f45daa7dab1116958cf53T.jpg)
![](https://sc01.alicdn.com/kf/Hffd503bb4d3243ac9daf6e32f57f21e6w.jpg)
![](https://sc01.alicdn.com/kf/H5f4073675fe543a88828548b3175955bS.jpg)
![](https://sc01.alicdn.com/kf/Hd684e643da9442d0a059b363453a5943F.jpg)
Specification
product name
|
YG-FD5 wind turbine
|
Rated power
|
5kw
|
Peak power
|
7kw
|
Start-up wind speed
|
3m/s
|
Working wind speed
|
4-30m/s
|
Survival wind speed
|
45m/s
|
Rotor diameter
|
5.2m
|
Blade
|
3pcs reinforced fiber glass
|
Blade length
|
260cm
|
Shell material
|
Carbon steel
|
Rated RPM
|
300r/m
|
Weight
|
260kg
|
